ETS files

KNX Clarity stores every exported .knxproj file as a versioned attachment on the owning project. Each version is parsed once and the extracted rooms, devices, and group addresses are written to the project so that you can browse them in the web UI without opening ETS.

Where to find it

The ETS upload + version history lives inside a project on the Pläne tab (Plans). The tab combines architect plans (PDF / image) and ETS exports — the old standalone "ETS files" tab was folded into this unified surface so you have one place to point at when telling a colleague where the source files live.

Uploading a file

Open the project detail, switch to the Pläne tab, and click Datei hochladen ("Upload file"). A file picker appears; choose a .knxproj (ETS 5 or ETS 6 format, up to 200 MB), optionally add a comment, and confirm.

Desktop

Mobile

During upload you'll see a progress bar. When the upload completes:

1. The file is stored in encrypted project storage.
2. The zip is parsed in the background, and the project's rooms, devices, and group addresses are upserted from the extracted XML.
3. The version row moves from parsing to ready.

Parsing usually completes in under 10 seconds for a typical single-family home. Larger commercial projects can take up to a minute; refresh the tab if it looks stuck.

Versioning

Every upload creates a new version, never overwrites the previous one. Version numbers are dense (v1, v2, v3, …) and assigned server-side, so two technicians can upload simultaneously without a collision.

Desktop

Mobile

Each row shows:

• Version number
• Original filename
• File size
• Uploader name
• Upload timestamp
• Comment (if any)
• Parse status

Downloading

Click the download button on any version to fetch the original .knxproj. Downloads are served via a short-lived signed URL valid for 15 minutes — if the link expires, click download again.

Beta limitation

Cross-organisation downloads (when you're reviewing a project that was transferred to you from another org) are on the short-list for the next beta release and are currently gated to the uploading user's identity. If you need urgent access to a file your colleague uploaded, either re-upload from an ETS backup on your own machine or ask them to share it over your usual out-of-band channel.

What the parser extracts

Entity	Shown under
Rooms	Rooms & devices → tree
Devices	Rooms & devices → device list
Group addresses	Group addresses tab
Manufacturers	Matched to catalog, linked from device rows

Anything ETS knows about but KNX Clarity does not yet surface in the UI (bus couplers, parameters, communication objects, scenes) is not lost — it stays in the parsed metadata and becomes available the moment we ship a page for it.

Replacing a corrupt upload

If a version ended up in error status (parser failure, truncated upload, wrong file format) the row shows a red status badge with the short error message. Click ⋮ → Delete version to remove it, then upload again. Deleting an error version leaves the earlier parsed state untouched.

Comment convention

We recommend writing a one-line comment on every upload explaining what changed since the previous version. This becomes the project's audit trail and is the first thing a service technician opens months later. Good examples:

• Added 3x dimmer in kitchen, reassigned GA 1/2/15 to the island
• Fixed typo in EG-WC switch name
• Initial commissioning export
